Fully automatic rotary surface grinding machine with a unique mechanism design combined with CNC technology.
The "SPG300" is a fully automatic rotary surface grinding machine that combines our unique mechanism design with CNC technology, enabling stable control and correction from ultra-low speeds to high speeds. By incorporating cermet thermal spraying on the table surface, it prevents wear and allows for easy attachment and detachment of workpieces. 【Features】 ■ Stable control and correction from ultra-low speeds to high speeds ■ Cermet thermal spraying is used on the table surface ■ Prevents wear and allows for easy attachment and detachment of workpieces *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
basic information
【Specifications】 ■ Maximum workpiece height: 80mm ■ Workpiece swing diameter: φ360mm ■ Magnet chuck diameter: φ330mm ■ Grinding wheel diamond outer diameter: φ180mm ■ Table rotation speed: 2 to 30 mm-1 ■ Spindle rotation speed: 2600 min-1 ■ Automatic feed speed: 0.1μm to 1mm/min ■ Grinding wheel axis elevation rapid feed speed: 100mm/min ■ Electric motors used ・ For spindle: Standard 1.5kw ・ For table: 120w ・ For coolant pump: 100w ■ Machine dimensions ・ Width: 855mm ・ Depth: 730mm ・ Height: 1390mm ■ Machine weight: 780kg *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the PDF document or feel free to contact us.
catalog（2）
Download All Catalogs
Company information
Sansin Seiki Co., Ltd. is a company that primarily engages in the design, manufacturing, and sales of machine tools, optical machinery, various specialized machines, and labor-saving machines. Our main product is the vertical axis rotary surface grinding machine (SPG series), which combines our unique mechanism design with CNC technology to enable stable control and correction from ultra-micro low speeds (0.01 microns per minute) to high speeds. We also handle a variety of other specialized equipment. We respond to user needs and can accommodate special specifications, so please feel free to contact us if you have any requests.
