Improve the development speed of semiconductor component manufacturing lines! Achieve quality enhancement with 3D CAD.
We would like to introduce a case study of business improvement using the 3D CAD specialized in mechanical design, "iCAD SX." At "Rohm Co., Ltd.," they have been internalizing semiconductor manufacturing equipment and have been working for many years to transition to 3D design in order to reduce interference and assembly issues. After careful consideration, they initially introduced a 3D CAD but abandoned its operation. They pointed out issues such as the difficulty in handling models due to strict rules when attempting team design, and that it took over 30 minutes to display files for 2,000 parts. Seeking "flexible team design" and "operability and speed akin to drawing with a pencil on paper," they selected "iCAD SX" and successfully improved business efficiency through 3D design. 【Main Effects of Implementation】 - Streamlining of upstream design processes and reduction of design development time - Activation of design reviews with related departments due to improved visibility of drawings - Interference suppression and reduction of man-hours through motion simulation of 6-axis robots 【Download Materials】 - Currently available for limited access on the special website. Please click the link below. ▼▼▼ Click here ▼▼▼
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX" is a purely domestic 3D CAD specialized for mechanical equipment design. It continues to pursue a commitment to being "light" and "fast" through its unique CAD kernel technology, achieving overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information accumulated in 3D data with ease. The extensive "manufacturing information" accumulated can be utilized not only in design but also in manufacturing and maintenance services, contributing to the reduction of development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Delivery Time
P3
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Examples of design targets: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveyor systems, industrial machinery and plants, food machinery, jigs and tools, precision machinery such as motors, and others.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
