The introduction of iCAD SX has achieved a dramatic increase in the speed and efficiency of design work, promoting the long-standing challenge of reforming design operations through 3D CAD.
We will introduce a case study of business improvement using the 3D CAD specialized in mechanical design, "iCAD SX." "Ebara Corporation" decided to transition to 3D design in order to aim for further compactness and high functionality in the design of semiconductor manufacturing equipment. However, due to a mismatch with the 3D CAD, issues arose such as an increase in design man-hours, enormous infrastructure investment, and frequent defects during equipment assembly that should have been reduced. The company made the decision to review their 3D CAD. After analyzing and quantitatively evaluating their design operations, they selected "iCAD SX," achieving a dramatic increase in the speed and efficiency of their design work. [Main Effects of Implementation] - Efficiency of design operations through simplification of modeling rules - Cost reduction effects (due to advancing production preparation and preventing rework) - Realization of digital collaboration and true top-down design [Download Materials] - Currently available for limited access on the special site. Please click the link below. ▼▼▼ Click here ▼▼▼
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX" is a purely domestic 3D CAD specialized for mechanical equipment design. It continues to focus on being "light" and "fast," pursuing its unique CAD kernel technology to achieve overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information accumulated in 3D data with ease. The accumulated extensive "manufacturing information" can be utilized not only in design but also in manufacturing and maintenance services, contributing to the reduction of development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Delivery Time
P3
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Examples of design targets: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveyor equipment, industrial machinery and plants, food machinery, jigs and tools, precision machinery such as motors, and more.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
