Reduced the startup period of the production line for PCs by 40%! Robot simulation on 3D CAD.
We will introduce a case study of business improvement using the 3D CAD "iCAD SX," specialized in mechanical design. At "Shimane Fujitsu Co., Ltd.," they are in-sourcing the production equipment for laptops and other devices. They decided to transition to 3D design to enable vertical startup during the switch of over 20 models. In response to the challenges of optimal robot placement and the design and manufacturing of jigs that arise with each work change, they designed and virtually verified using iCAD SX, reducing the line startup period by 40%. By shortening the startup period and reducing rework, they were able to secure more time for consideration in the planning phase of the equipment. 【Main Effects of Implementation】 - The startup period after equipment installation was reduced from 5 days to 3 days. - Robot simulation, including surrounding equipment, became possible on the 3D CAD. - Interference was significantly suppressed in 3D design. 【Document Download】 - Currently available for limited access on the "special site." Please click the link below. ▼▼▼ Click here ▼▼▼
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX" is a purely domestic 3D CAD specialized for mechanical equipment design. It continues to pursue a commitment to being "light" and "fast" through its unique CAD kernel technology, achieving overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information accumulated in 3D data with ease. The extensive accumulated "manufacturing information" can be utilized not only in design but also in manufacturing and maintenance services, contributing to the reduction of development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Delivery Time
P3
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Design target examples: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveying equipment, industrial machinery and plants, food machinery, jigs and tools, precision machinery such as motors, and others.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
