Photo sensors that detect people and objects and play an active role in smart factories.

basic information

【Motion Sensor (KM Series)】 <A limited reflection type photo sensor series adopting a triangulation method suitable for human detection and more> [Detection Distance] A product range covering a wide detection distance of 5cm to 200cm. Each model has detection distance settings in increments of 5cm or 10cm. [Resistance to Ambient Light] Under specified conditions where direct sunlight does not enter, the sensor surface has a resistance to ambient light of 30,000 lux, and the reflective surface has a resistance of 24,000 lux. 【Distance Measuring Sensor KR5471】 <A distance measuring sensor that integrates a PSD (Position Detection Element), IRED (Infrared Emitting Diode), and signal processing circuit> [Detection Distance] Long-range type (distance measurement range: 100 to 550cm) [Power Supply Voltage Specification] Analog output type 【Separated Photo Sensor, Light Modulation Type KB3725】 <A separated photo sensor that uses an infrared emitting diode on the emitting side and a modulated photo IC on the receiving side> [Detection Distance] Long-range type (max. 2m) [Operation Type] Light modulation asynchronous type [Power Supply Voltage Specification] Open collector output [Ambient Light Tolerance] max. 50,000 lx ● For more details, please contact us or refer to the catalog.

Price information

Please contact us.

Delivery Time

Applications/Examples of results

●Motion Sensor (KM Series) 【Applications】 ◎ Detection of humans and objects for security and safety devices ◎ Detection of toilet lid opening and closing, automatic faucet hand detection ◎ Human detection for ATMs and automatic change dispensers ◎ Seat detection and non-contact switches for amusement machines ◎ Detection of object presence for medical devices ●Distance Sensor KR5471 【Applications】 ◎ Projectors ◎ Robot vacuum cleaners ◎ Automatic switches for lighting, etc. ◎ Human detection devices ◎ Amusement machines (gimmick detection, arcade game machines) ●Separated Photo Sensor, Light Modulation Type KB3725 【Applications】 ◎ Detection and positioning of workpieces in automation lines ◎ Human passage detection for security gates and ticket gates at stations ◎ Detection of prize drop in prize games ●For more details, please contact us or refer to the catalog.

Line up（190）
