If it's our stock items, we can provide immediate delivery!
Polyester Film Capacitors ~UMXR Series Available~ ・1HUMXR102JE ・1HUMXR103JE ・1HUMXR104JE ・1HUMXR122JE ・1HUMXR123JE ・1HUMXR124JE ・1HUMXR152JE ・1HUMXR153JE ・1HUMXR154JE ・1HUMXR182JE ・1HUMXR183JE ・1HUMXR184JE ・1HUMXR222JE ・1HUMXR223JE ・1HUMXR224JE ・1HUMXR272JE ・1HUMXR273JE ・1HUMXR274JE ・1HUMXR332JE ・1HUMXR333JE ・1HUMXR334JE ・1HUMXR392JE ・1HUMXR393JE ・1HUMXR394JE ・1HUMXR472JE ・1HUMXR473JE ・1HUMXR474JE ・1HUMXR562JE ・1HUMXR563JE ・1HUMXR682JE ・1HUMXR683JE ・1HUMXR882JE ・1HUMXR823JE
Inquire About This Product
basic information
- It uses polyester film as a dielectric, providing excellent performance. - Its compact and lightweight design makes it suitable for automatic insertion. - The exterior is made of epoxy resin, which excels in heat resistance, moisture resistance, and solvent resistance. Operating temperature range: -40°C to +85°C Dissipation factor: 1.0% MAX. (at 20°C, 1kHz) Insulation resistance: 30,000 MΩ Min. Withstanding voltage: WV × 2.5 (1~5 sec) Capacitance tolerance: ±5% (J)
Price range
Delivery Time
Applications/Examples of results
Compatible with Rubicon product 50F2D272J (with dimensional differences).
