The groove pitch tolerance is ±0.005! An example performed using a machining center and grinding.
We would like to introduce a case study of machining a tool holder for machine tools by Nisshin Co., Ltd. The groove pitch tolerance is ±0.005, and the bottom thickness tolerance is ±0.01. We achieved a parallelism of 0.01 at five locations. Additionally, we have machining achievements using machining centers, so please feel free to contact us when needed. 【Case Overview】 ■ Machining Method: Machining Center × Grinding ■ Material: S45C and Cast Iron ■ Key Points ・ Groove pitch tolerance ±0.005 ・ Parallelism of 0.01 at five locations ・ Bottom thickness tolerance ±0.01 *For more details, please download the PDF or feel free to contact us.
Inquire About This Product
basic information
For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please download the PDF or feel free to contact us.
catalog（3）
Download All Catalogs
Company information
Nisshin Co., Ltd. is a company that engages in general metal machining and assembly. We respond with integrated production from design, processing, to assembly, and realize our customers' advanced needs with unique production know-how that cannot be replicated by other companies. Our motto is "Better products, at lower costs, more quickly," and we have continuously worked as a united company to provide products that satisfy our customers. Moving forward, Nisshin aims to become a creative and high-tech group towards a new future.
