Achieving outstanding high specifications and high performance through air bearing technology.
Adoption of air dynamic pressure bearings Ultra-compact / lightweight High static pressure Low vibration Long lifespan due to bearing configuration unaffected by heat Adoption of quick couplings P14 (intake / exhaust) Use of UL94 V0 rated resin materials
Inquire About This Product
basic information
Rated voltage: 10 to 30 VDC Rated power supply current: 0.9 A or less Rated power consumption: 21.6 W or less Operating speed range: 6,000 to 45,000 rpm Minimum flow rate: 5 L/min Operating ambient pressure: 770 to 1,060 hPa Noise: 65.0 dB(A) or less Mounting hardware: Included Weight: 165 g Material used: UL94 V0 certified resin Remarks: Dedicated driver sold separately
Price range
Delivery Time
Applications/Examples of results
Fuel cells, medical devices, communication equipment, etc.
Company information
Since its establishment in 1967, our company has created numerous products for the electronics industry. As a result of our pursuit of advanced technology, we have included world-first and domestic-first new products among them. Additionally, we have been consistently supplying high-quality products, which has earned us recognition from a wide range of customers. Consequently, our trimmer potentiometers have achieved approximately 50% market share in the domestic market. Other various products also possess high marketability. We are actively responding to market needs. We are committed to meeting your needs, so please feel free to let us know.
