PICO 2.5" Boat PICO-ADN4
PICO-ADN4W2-0002 (Heat Sink + Heat Spreader) ・AAEON
Low power consumption × high performance - Single board computer equipped with AM62
The PICO-AM62 is a low-power, high-cost-performance single-board computer equipped with the Texas Instruments Sitara AM62x processor. It features a single or quad Arm Cortex-A53 core, along with an independent Cortex-M4F core, supporting hybrid control of Linux and RTOS. It is ideal for a wide range of applications, including industrial equipment, HMI, gateways, and edge AI. **Key Features** - Equipped with TI Sitara AM62x processor (up to 1.4GHz Quad-Core Arm Cortex-A53) - Abundant I/O options (Gigabit LAN, USB 3.0, UART, GPIO, CAN-FD, etc.) - Dual display output (supports LVDS + HDMI) - Excellent expandability: M.2 / miniPCIe slot for communication module expansion - Low power design supports fanless operation - Long-term supply and industrial temperature models available
Inquire About This Product
basic information
●100mm x 72mm ●ARM TI AM6232/6254 Dual/Quad-core Cortex-A53 1.4GHz ●2G/4G onboard memory ●16G onboard eMMC storage ●HDMI 1.4b×1 (only for model 0002), LVDS×1, GbE×1 (model 0001)/x2 (model 0002) ●USB 2.0 host/device×1, USB 2.0×2 ●COM x2 (model 0001)/x4 (model 0002), CAN×2, TPM 2.0 (only for model 0002) ●Mini card x 2 (half x 1, full x 1) ●Standard product comes with Debian 12 (without GUI) ●Operating temperature -40°C ~ 85°C
Price range
Delivery Time
Applications/Examples of results
Industrial HMI / Control Terminal Gateway / Edge AI Processing Digital Signage Smart Retail Terminal Embedded Devices such as Medical and Inspection Equipment
