No power outage work or equipment modifications are necessary! Continuous diagnostics can be performed on special high-voltage cables without power outages.
"PDLOOK" is a service that conducts continuous remote diagnosis and reporting of the health of private internal cables without power interruption. It features diagnostic technology that enables continuous remote diagnosis using partial discharge methods. This power outage-free remote diagnosis is also applicable to extra-high voltage cables. Since it requires minimal initial costs, it is easy to implement and can be used as evidence data for budget applications (cable replacement costs). 【Features】 ■ Diagnosis can be performed while keeping the production line operational, eliminating the need for power outage work. ■ Reduces labor related to on-site responses for production stop planning adjustments and diagnosis. ■ Enables early detection of abnormalities from the initial stages of deterioration through trend monitoring with 365-day diagnosis. ■ Applicable to extra-high voltage cables. ■ Monthly reports provide diagnosis results every month (accessible anytime via browser). *For more details, please download the PDF or feel free to contact us.
Inquire About This Product
basic information
【System Configuration Overview】 <Kyuden Assets> ■ High-frequency CT sensor (installed on grounding wires of private in-house cables with 3kV or more) ■ Detection device main unit + independent stand + light shield (choose between wall-mounted or free-standing based on installation location, and whether a light shield is needed) ・ Main unit: 550×300×600mm (width×depth×height) ・ Free-standing: 630×455×910mm (width×depth×height) ■ PDLOOK Cloud (connected via closed network LTE line, managed and operated at the data center) <Customer Assets (wiring locations for installation work)> ■ Communication cables, 100V power supply cables, Type D grounding *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Recommended Customers】 ■ Businesses that own and manage special high-voltage cables (Especially large manufacturing companies that own significant factories) ■ Other businesses that are facing challenges or dissatisfaction with their current cable diagnostics *For more details, please download the PDF or feel free to contact us.
