The FPGA workbench achieves improved signal processing accuracy and cost reduction.
In the aerospace industry, the field of signal processing requires advanced data processing capabilities and real-time performance. Particularly in aircraft control systems and communication systems, accurate signal processing is essential for safe operations. The FPGA Workbench consists of application builder/configurator software for customers using FPGA cards and built-in IP cores on the iHawk computer, as well as proprietary IP cores. Customers can freely combine standard IP cores provided in advance by Concurrent Real-Time and can also implement their own created IP cores. 【Use Cases】 - Aircraft flight control systems - Signal processing for satellite communication systems - Data processing for radar systems 【Benefits of Implementation】 - Acceleration and high precision of signal processing - Improved flexibility and scalability of the system - Reduction in development time and costs
Inquire About This Product
basic information
【Features】 - Ability to select various data acquisition and industry-specific IP cores - Intuitive operability with a powerful GUI - Abundant I/O functions such as analog I/O and digital I/O - Customizable for each FPGA board - Supports 362K or 504K logic elements 【Our Strengths】 Concurrent Computer Corporation has been a leader in real-time computing technology for over 50 years. Starting with the real-time OS RedHawk Linux, we accurately understand our customers' needs and provide timely solutions.
Price information
1) Programmable FPGA PCIe Card, 362K CP-FPGA-2 2) Programmable FPGA PCIe Card, 504K CP-FPGA-3 3) FPGA Workbench Software License WU8021-300 4) Concurrent Real-Time Company's standard IP cores, 28 types *All prices are excluding tax.
Price range
P6
Delivery Time
※The standard delivery time for iHawk computers is 3 months (delivery times may vary depending on configuration and software setup). Please feel free to contact us.
Applications/Examples of results
Using the mechanism of the FPGA workbench, the following I/O cards have been created by our company: - 64-channel, 18-bit SAR analog input - 32-channel, 24-bit delta-sigma analog input - 32-channel and 8-channel, 18-bit analog output - 12-line pulse width modulation output - 12-line pulse width modulation input - Multifunction 16-channel A/D, 16-channel D/A, 96-line digital - SENT protocol with 12 inputs and 12 outputs - 4-channel universal exhaust gas oxygen (UEGO) - 16-line resistance simulation - State change of 64-channel digital input - 4-line wheel speed sensor - Universal exhaust gas oxygen (UEGO) sensor We have a proven track record in conducting engine simulations equipped with each signal using a combination of our standard IP cores (crank, cam, ignition, injection) in Japan, Germany, and the United States.
Line up（26）
| Model number | overview |
|---|---|
| ICS-FPGA-2002 | User HDL Code License |
| ICS-FPGA-2003 | LVDT/RVDT TX License, 1 line |
| ICS-FPGA-2004 | LVDT/RVDT RX License, 1 line |
| ICS-FPGA-2005 | Synchro TX License, 1 line |
| ICS-FPGA-2006 | Synchro RX License, 1 line |
| ICS-FPGA-2007 | Crank/Cam License, 4 lines |
| ICS-FPGA-2008 | Ignition Injection License,1 line |
| ICS-FPGA-2009 | PWM In I/O License, 1 line |
| ICS-FPGA-2010 | PWM Out I/O License, 1 line |
| CS-FPGA-2011 | Wheel Speed Sensor License, 1 line |
| ICS-FPGA-2013 | SENT Receiver License, 1 line |
| ICS-FPGA-2014 | SENT Transmit License, 1 line |
| ICS-FPGA-2015 | Angular Encoder License, 1 line |
| ICS-FPGA-2016 | Angular Decoder License, 1 line |
| ICS-FPGA-2017 | Knock Sensor Output License, 1 line |
| ICS-FPGA-2018 | Analog Threshold License, 1 line |
| ICS-FPGA-2019 | 3-Phase Inverter License, 1 line |
| ICS-FPGA-2020 | PMSM Motor License, 1 line |
| ICS-FPGA-2021 | Waveform Generation License, 1 line |
| ICS-FPGA-2022 | High-Pressure Fuel Punp License, 1 line |
| ICS-FPGA-2023 | DIO Change-Of-State License, 64 lines |
| ICS-FPGA-2024 | Field Oriented Control (FOC) License, 1 line |
| ICS-FPGA-2025 | PWM 3-Phase License, 1 line |
| ICS-FPGA-2026 | UVW Encoder License, 1 line |
| ICS-FPGA-2028 | FPGA Workbench Resolver TX License, 1 line |
| ICS-FPGA-2029 | Resolver RX License, 1 line |
