The output capacities are available in 15W, 30W, 65W, 120W, 150W, 240W, 250W, 320W, and 500W!
We would like to introduce the "OPEN FLAME Power Supply" that we handle. This is a product from UE Electronic, a reputable medical power supply manufacturer established in 1989 in the Songshan Lake High-Tech Industrial Zone in Guangdong Province, China, equipped with advanced automatic facilities. The output capacities available are 15W, 30W, 65W, 120W, 150W, 240W, 250W, 320W, and 500W. The 250W model is available in both separate FAN type and FAN-equipped type. 【Features】 ■ Complies with 2xMOPP ■ Medical standard IEC60601-1 ■ Certified under IEC62368 *For more details, please download the PDF or feel free to contact us.
Inquire About This Product
basic information
For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please download the PDF or feel free to contact us.
Line up（10）
| Model number | overview |
|---|---|
| Output capacity: 15W Output voltage: 5V to 24V, 3.0A max | Size (Length × Width × Height mm): 54.0 X 36.8 X 20.3 Model: UES15D-SPA Features: Leakage current ≤ 100μA Standby power: ≤ 0.25W Safety standards: Compliant with medical standard 60601-1, compliant with communication standard 62368 |
| Output capacity: 30W Output voltage: 5V to 24V, 6.0A max | Size (Length × Width × Height mm): 70.0 X 48.0 X 24.5 Model: UES30D-SPA Features: Leakage current ≤ 100μA Standby power: ≤ 0.3W Safety standards: Compliant with medical standard 60601-1, compliant with communication standard 62368 |
| Output capacity: 65W Output voltage: 5V to 48V, 10.0A max | Size (Length × Width × Height mm): 76.2 X 50.8 X 27.5 Model: UES65-SPA5-OP Features: Energy efficiency level VI Leakage current ≦ 100μA Standby power: ≤ 0.15W Safety standards: Medical IEC60601-1 Communication IEC62368 |
| Output capacity: 120W Output voltage: 12V to 54V, 10A max | Size (L×W×H mm): 76.2 X 50.8 X 31.0 Model: UES120-SPAZ-OP Features: Efficiency 95%, peak load support Leakage current ≦ 100μA Standby power: ≤ 0.5W Safety standard: Medical IEC60601-1 |
| Output capacity: 240W Output voltage: 12V to 54V, 18A max | Size (Length × Width × Height mm): With aluminum frame 127.0 X 76.2 X 34.5 Model: UES240-SPA-OP Features: Energy efficiency level VI Leakage current ≦ 100μA Standby power: ≤ 0.21W Safety standard: Medical IEC60601-1 |
| Output capacity: 150W Output voltage: 12V to 54V, 12.5A max | Size (L×W×H mm): 101.6 X 50.8 X 35.3 Model: UES250-SPAZ-OP Features: Efficiency 94% Leakage current ≦ 100μA Standby power: ≤ 0.5W Safety standards: Compliant with medical 60601-1, compliant with communication 62368 |
| Output capacity: 250W Output voltage: 12V to 54V, 20.83A max | Size (Length × Width × Height mm): Separate FAN type 119.0 X 64.0 X 43.0 Model: UES250-SPAZ-OPC Features: Efficiency 94% Leakage current ≦ 100μA Standby power: ≤ 0.5W Safety standards: Compliant with medical standard 60601-1, compliant with communication standard 62368 |
| Output capacity: 250W Output voltage: 12V to 54V, 20.83A max | Size (Length × Width × Height mm): With FAN Vertical: 119.0 X 64.0 X 58.0 Model: UES250-SPAZ-OPTF Features: Efficiency 94% Leakage current ≦ 100μA Standby power: ≤ 0.5W Safety standards: Compliant with medical standard 60601-1, compliant with communication standard 62368 |
| Output capacity: 320W Output voltage: 12V to 54V, 26.66A max | Size (Length × Width × Height mm): 127.0 X 76.2 X 41.0 Model: UES500-SPAZ-OP Features: Efficiency 94% Leakage current ≦ 100μA Standby power: ≤ 0.5W Safety standards: Compliant with medical standard 60601-1, compliant with communication standard 62368 |
| Output capacity: 500W Output voltage: 12V to 54V, 41.66A max | Size (Length × Width × Height mm): With FAN (Position = External/Vertical/Horizontal) Horizontal: 160.0 X 68.0 X 43.0 Model: UES500-SPAZ-OPSF Features: Efficiency 94% Leakage Current ≦ 100μA Standby Power: ≤ 0.5W Safety Standards: Compliant with Medical 60601-1, Compliant with Communication 62368 |
