Bridge measures for fibrous powdered raw materials! Introducing case studies of solutions by powder handling professionals!!
To prevent bridging of fibrous powder materials in the screw feeder hopper, we have decided to install this bridge breaker. The bridge breaker features a rubber disk that is normally (when air is OFF) in close contact with the inner wall of the hopper, but when air is ON, this rubber disk slightly lifts away from the inner wall, allowing air to be injected through the gap. Simultaneously, the elastic disk vibrates, and through these actions, we were able to easily resolve the bridging of the materials. 【Overview】 (Mounting Location) - Powder hoppers in manufacturing plants for ceramics, tiles, etc. (Hopper Overview) - Dimensions: 800×1400, two sides inclined at 1400 width, with the 800 width side vertical and a screw feeder at the bottom. (Mounting Location and Number of Installations) - A total of 6 units, 3 on each 1400 width side: all at the same height. (Controller and Operating Sequence) - A controller with 4 built-in solenoid valves is used: 4 output air lines. - 2 blow disks are installed for each output air line, with 2 blow disks sequentially turned ON at 3 locations. *For more details, please contact us or download the catalog for further information.
Inquire About This Product
basic information
【Specifications】 ○ Brody Disk BD-15S-B, 6 pieces ○ Controller C-SV4, 1 unit 【Key Points of This Equipment】 ■ The strength and durability of the elastic disk (silicone) are very important from the perspective of foreign matter contamination risk. The silicone disk of this equipment is exceptionally strong and durable. Once you use it, you will understand! ■ Control (how to aerate?) is crucial! We provide guidance on what should be done. A dedicated controller is also available. *For more details, please contact us or download the catalog to view.
Price information
For more details, please contact us.
Delivery Time
Applications/Examples of results
Please contact us.
