Prevent bridging of granules with high moisture content! Introducing case studies from powder handling professionals!
The high moisture content of the granulated material caused bridging at the hopper outlet, but the installation of the Brody Disk and Brody Disk Mini resolved the issue. Initially, you were using an overseas vibrator (air ball type), which was effective but occasionally caused bridging, leading you to contact us. 【Overview】 (Usage Conditions) ○ About the Hopper → Top: 800φ, Outlet: 80φ, Angle of repose: approximately 60° ○ Raw Material → Particle size: approximately 5φ, Moisture content: over 20% ○ Installation Position and Model → The risk of blockage is highest just above the outlet, so two Brody Disk Minis were installed in this location (75mm above the hopper wall from the outlet). → Due to the hopper's radius in this location, a Brody Disk cannot be installed; only Brody Disk Minis can be used. → It is preferable to install close to the outlet, so Brody Disk Minis were chosen. → Two Brody Disks were installed approximately 150mm above the Brody Disk Minis along the hopper wall. *For more details, please contact us or download the catalog to view.
Inquire About This Product
basic information
【Specifications】 ○ Brodisk Mini BD-08S-W x 2 ○ Brodisk BD-15S-W x 2 ○ Controller C-SV1 x 1 【Key Points of This Equipment】 ■ The strength and durability of the elastic disk (silicone) are very important from the perspective of foreign matter contamination risk. The silicone disks of this equipment are exceptionally strong and durable. Once you use them, you will understand! ■ Control (how to aerate?) is important! We provide guidance on what should be done. A dedicated controller is also available. *For more details, please contact us or download and view the catalog.
Price information
For more details, please contact us.
Delivery Time
Applications/Examples of results
Please contact us.
