A portable hydrogen sulfide analyzer capable of measuring 0 to 2,000 ppm!
● High response speed, long lifespan, disposable proprietary patented sensor ● Realization of miniaturization - new book size, weight approximately 2.2 kg ● Measurement at PPM levels ● Data logging function ● Three range output switching available (high concentration option available) ● Various settings possible via PC connection ● Simple operability ■ The Model 3000RS is a portable hydrogen sulfide analyzer characterized by its simple operability. ■ The galvanic cell type (electrochemical) patented sensor used in this product achieves high response speed and long lifespan by incorporating unique thin-film technology. ■ Changes in flow rate do not affect the measurement values. ■ The main unit is equipped with a standard data logging function capable of storing up to 20,000 points, allowing logging to start with the push of a button, and data can be downloaded to a PC using dedicated software. *For more details, please download the catalog or contact us.*
Inquire About This Product
basic information
Model: 3000RS Measurement Range: 0-200/0-2000 pm Measurement Accuracy: FS±1% Power Supply: Nicd Battery Power Consumption: 10 W or less Output: 0 – 1 VDC, USB connection Flow Rate: 0.1–1.0 L/min Operating Pressure: Primary side (upstream of the oxygen concentration meter): 3.0 kPaG to 0.1 MPaG Secondary side (downstream of the oxygen concentration meter): Atmospheric open
Price range
Delivery Time
P4
Applications/Examples of results
● Management of hydrogen sulfide as an impurity Among other diverse aspects
