This is a mirror that is resistant to damage from high-energy UV lasers due to IBS coating.
Manufacturer: OPTOMAN (Lithuania) To achieve a high reflectivity in the ultraviolet wavelength range, it is necessary to effectively control scattering and absorption losses. For UV laser users, mirror degradation is a significant issue. OPTOMAN has focused on surface quality and optimized coating technology. This technology protects optical elements from UV lasers and extends their lifespan.
Inquire About This Product
Related Videos
basic information
◆Specification Example◆ Substrate: UVFS (ultraviolet transmitting grade synthetic quartz glass) Surface Quality: 10-5, S-D Flatness: λ/8 @ 633 nm over CA Incident Angle: 45° Coating: HRsp > 99.7% (@ design wavelength) Damage Threshold: 1) 343 nm - picosecond > 0.27 J/cm2, 343 nm, 1 ps, 50 kHz, p-pol > 0.52 J/cm2, 343 nm, 1 ps, 50 kHz, s-pol 2) 355 nm - nanosecond > 6.97 J/cm2, 355 nm, 6 ns, 100 Hz, p-pol > 9.6 J/cm2, 355 nm, 6 ns, 100 Hz, s-pol 3) 355 nm - picosecond > 0.25 J/cm2, 355 nm, 1 ps, 50 kHz, p-pol > 0.5 J/cm2, 355 nm, 1 ps, 50 kHz, s-pol
Price range
Delivery Time
Applications/Examples of results
● High-power UV laser ● Laser processing equipment
