The measurement range is 14mm! Introducing our high-precision non-contact linear stroke measurement system!
The "LPS4.0 14 IO" is a linear stroke control system using electromagnetic induction. It features a compact design that makes installation easy. Since it does not use magnets, it is not affected by iron powder. The output is an analog signal of 0-10V (Id.No.208106), and it has a protection rating of IP67, compatible with IO-Link. 【Features】 ■ High-precision non-contact linear stroke measurement system ■ Electromagnetic induction method ■ Not affected by iron powder due to the absence of magnets ■ Measurement range = 14mm ■ Protection rating IP67 *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
basic information
【Technical Specifications】 ■Measurement Range: 14mm ■Signal: 0-10V ■Power Supply: 24V DC ■Measurement Accuracy: ±0.05mm ■Linearity: ±0.20mm ■Temperature Variation: 0.25mm ■Operating Temperature: 10-60° ■Protection Rating: IP67 ■Interface: IO-Link 1.0 ■MTTFd: 490a ■Mission Time (TM): 20a ■Self-Diagnosis Rate (DC): 0% *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the PDF document or feel free to contact us.
