Shibaura Mechatronics Co., Ltd. [3D CAD Implementation Case] i CAD SX
A 3D CAD that smoothly carries out the assembly design of 40,000 parts, achieving "zero interference" and "reduction of rework in the manufacturing process."
We would like to introduce a case study of business improvement using the 3D CAD "iCAD SX," which is specialized in mechanical design. "Shibaura Mechatronics Corporation" decided to transition to 3D design in order to improve the efficiency of their semiconductor manufacturing equipment design operations. After comparing three products: an existing 2D CAD from the same manufacturer, a high-end 3D CAD, and iCAD SX, they selected "iCAD SX" as the only one that could withstand practical use. As a result, despite being custom-made products without a prototyping process, they achieved "zero interference" at the design stage. By utilizing 3D data and a viewer, they successfully reduced the man-hours required for creating assembly instruction manuals. [Main Benefits of Implementation] - Achieved "zero interference" at the design stage, reducing rework costs in the manufacturing process. - Reduced design time by 30% compared to the time estimated with 2D CAD. - Increased inquiries through visual appeal. [Download Materials] - Currently available for limited access on the special site. Please click the link below. ▼▼▼ Click here ▼▼▼
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX" is a purely domestic 3D CAD specialized for machine equipment design. It continues to focus on being "light" and "fast," pursuing its unique CAD kernel technology to achieve overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information accumulated in 3D data with ease. The extensive "manufacturing information" accumulated can be utilized not only in design but also in manufacturing and maintenance services, contributing to the reduction of development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Design target examples: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveying equipment, industrial machinery and plants, food machinery, jigs and tools, precision machinery such as motors, and more.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
