[Case Study of 3D CAD Software for Mechanical Design] Sumitomo Heavy Industries Environment
COLMINA Design and Manufacturing Support iCAD SX
[Free Case Study Provided] Smoothly convert existing 2D data to 3D, reducing design time by 22%!
We would like to introduce a case study of the implementation of "iCAD SX" at Sumitomo Heavy Industries Environment, a water treatment engineering company with top-class domestic market share. At the company, after determining the core concept and basic specifications according to the required dimensions of the order drawings, they check for interferences and optimize the operator's workflow before the cooperating manufacturers begin detailed design and manufacturing. "iCAD SX" was introduced to improve the accuracy and efficiency of this design work. After the implementation, they achieved front-loading of the design process and a 22% reduction in design lead time. Although there was a problem with a decreasing number of veteran designers, the use of 3D CAD has made spatial design considerations easier, leading to an improvement in the skills of existing designers. [Case Summary] ■Challenges - There is a decreasing number of veteran designers who can create 2D drawings while envisioning 3D shapes. ■Results - Achieved a 22% reduction in design time. - Unique use of "synchronous motion" alleviated concerns during the delivery process. *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX," is a purely domestic 3D CAD specialized in machine equipment design. - It continues to pursue a commitment to being "light" and "fast" through its unique CAD kernel technology, achieving overwhelming high-speed processing performance. - It operates smoothly even for the design of large-scale machinery and entire production equipment lines. - The vast accumulated "manufacturing information" can be utilized in design, manufacturing, and maintenance services, contributing to the reduction of development lead times. - It is adopted by many domestic companies and offers robust support unique to domestic development.
Price range
Delivery Time
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Examples of design targets: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveying equipment, industrial machinery and plants, food machinery, jigs and tools, precision machinery such as motors, and more.
catalog（2）
Download All Catalogs
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
