Achieve four functions with one device! This equipment is equipped not only for welding but also for cutting, rust removal, and cleaning.
Welding of dissimilar metals such as stainless steel, iron, and aluminum can achieve high-quality welds with minimal burn and distortion, serving as an alternative to TIG and arc welding. The swing function allows for adjustments to the welding width and penetration shape. Even beginners can achieve the same ease of operation as skilled professionals. ■ Laser Welding Function The swing function allows for adjustments to the welding width and penetration shape. ■ Cutting Function - Capable of processing materials with a thickness of 2mm or more - Materials: SUS, iron, galvanized steel sheets, aluminum, etc. ■ Welding Burn Removal Function - The appearance can become charred, making it more susceptible to corrosion. - It is important to remove burns through burn removal. ■ Cleaner Function Leave rust removal to us.
Inquire About This Product
basic information
■ Rated output: 1500W, 2000W ■ Oscillation control method: CW / Continuous wave ■ Laser wavelength: 1080nm ± 10nm ■ Frequency (Hz): 50 to 5000 ■ Cable length: 8m ■ Cooling method: Water cooling ■ Input power supply: Single-phase 220V ■ Power consumption: 8KW and above ■ Size (MM): Height 1050 × Depth 870 × Width 560 ■ Weight: 165KG and above ■ Head weight: 0.9KG ◎ Double wire feeding device (can be changed as an option)
Price range
Delivery Time
Applications/Examples of results
Anyone can easily weld with fiber welding. 【Welding and Cutting Materials】 SUS, steel, galvanized steel sheets, aluminum, etc.
Line up（1）
| Model number | overview |
|---|---|
| 2000N |
catalog（1）
Download All Catalogs
Company information
Chunichi Craft Co., Ltd. delivers high-quality products by consistently producing everything from the design of machine parts to manufacturing, hardening, surface treatment, welding, and molding. Since our founding, we have focused on surface treatment and plating of molds, which are the foundation of Japanese manufacturing, and have continually challenged ourselves in the development of various surface treatment technologies. Currently, we are dedicated to research and development of products that combine environmental measures with functional improvements. Please pay attention to our technology and development capabilities.
