J6412 TDP 10W (Elkhart Lake) CPU, fanless operation, 8×USB, 2×HDMI, 2×LAN, 2×COM
【Jetway HBFDF04-6412-V Features】 ■ Width 193 × Height 62 × Depth 142.4 mm ■ Equipped with J6412 TDP 10W (Elkhart Lake) CPU ■ 2× SO-DIMM slots DDR4-3200MHz (up to 32GB) ■ Supports maximum resolution 4K, 2 display outputs (2 HDMI) ■ 1× M.2 B-key (3042), 1× M.2 E-key (2230) expansion slots ■ 3× USB3.1 (Gen2), 3× USB2.0, 2× HDMI, 2× Intel i225V 2.5GbE ■ Wide power supply DC 12~24V ■ Compatible with Win10 & 11, Linux ■ Complies with CE, FCC, LVD, RoHS, ErP Ready certifications
Inquire About This Product
basic information
Specifications ■CPU: Intel Celeron J6412 (Elkhart Lake) processor ■Memory: 2×SO-DIMM slots DDR4-3200MHz (up to 32GB) ■Storage: 1×2.5” SATAIII, 1×M.2 M-Key slot (supports 2242/2280, PCIe Gen3 x2 / SATA, NVMe support) ■Expansion Slots: 1×M.2 B-key (3042), 1×M.2 E-key (2230) ■I/O Connectors: 3×USB3.1 (Gen2), 3×USB2.0, 2×HDMI, 2× Intel i225V 2.5GbE ■Power / Power Consumption: DC 12–24V power input / 60W ■Dimensions: Width 193× Height 62× Depth 142.4 mm ■Operating Temperature: 0–50°C ■Certifications: CE, FCC, LVD, RoHS, ErP Ready
Price information
Open price
Delivery Time
※It may vary depending on the quantity and timing, so please feel free to contact us.
Applications/Examples of results
For vehicle-mounted, machine, factory, and building automation/monitoring systems.
Line up（1）
| Model number | overview |
|---|---|
| HBFDF04-6412-V | Intel Elkhart Lake SoC processor, DDR4 up to 32GB, 2* HDMI, 12~24V DC-in |
