Ultra-lightweight at 173 grams! The smallest and lightest class. *As of June 2025, based on manufacturer research, compared to similar models from other companies.
■Compact Model A compact model that inherits miniaturization. The body weight is only 173 grams (including the battery).
Inquire About This Product
basic information
■Specifications Model Number: M474FRV-361S Light Source: 515nm±2% Green Semiconductor Laser Light Output: 2.5mW or less, Class 2 Pulse Width/Frequency: 50μs/10kHz±10% Mode Switching: 2 modes, Receiver (normal), High brightness Line Width: 1.5mm/5m Accuracy: ±1mm/5m Automatic Correction Range: ±3° Tilt Warning: Yes, laser light blinking Automatic Correction OFF Function: Yes Control Method: Magnetic braking method Battery Level Warning: Yes, power/mode switch lamp blinking Power Supply: Lithium-ion battery 3.7V 900mAh, Charging time: approximately 2 hours Continuous Use Time: Receiver mode: approximately 8 hours, High brightness mode: approximately 4 hours Operating Temperature Range: -10℃ to +45℃ Dust and Water Resistance: Equivalent to IP54 Tripod Mounting: Camera type, 1/4 inch Receiver Compatibility: Compatible, optional use (M474FRVS-30GS) Maximum Outdoor Range: Approximately 20m (When using optional M474FRVS-30GS, but may vary depending on usage environment) Main Unit Dimensions: φ36mm×115mm Main Unit Weight: 173g (including battery)
Price range
Delivery Time
Applications/Examples of results
■With theft and fire compensation STS Total Support (Note 1) Compensation period is one year from the day after purchase. (Registration is required at the time of purchase) (Note 1) Customers who purchase products with an attached application form for theft and fire compensation will be compensated in the event of fire or theft. (Accessories and tripods are not covered.)
