Reduction of labor and waste through thermocouple measurement with 'MiEL Thermo HT'
A system that reduces the number of manual thermocouple measurements through automatic temperature measurement, contributing to labor reduction and waste reduction.
In traditional manual thermocouple measurements, issues such as increased labor and waste generation were challenges. The "MiEL Thermo HT" automatically measures the temperature for each mold, reducing the number of thermocouple operations. 【Benefits of Implementation】 - Reduction in labor hours - Decrease in waste generation - Improved quality through stable data acquisition - Easy integration with existing equipment This is a temperature measurement solution that balances production efficiency and environmental impact reduction. For more details, please download the materials or feel free to contact us.
Inquire About This Product
basic information
【Standard Specification Example】 ● Equipment Configuration ・Complete optical equipment ・Other hardware set (such as PC) ・Temperature analysis software ● System Details (1) Measurement temperature range: 600℃ to 1600℃ (recommended above 1000℃) (2) Measurement range: 235mm×310mm (at a distance of 2.5m to the measurement target; varies with distance) (3) Measurement mode: Line measurement, area measurement (both equipped with automatic molten metal recognition function) (4) Input: Camera... Power supply via PC connection, PC... 100V power supply (5) Output: Instantaneous value, peak hold, moving average, average value per mold Data is saved in CSV format on the PC (6) Operating temperature: 0℃ to 50℃ * Air purge cooling mechanism is recommended for the camera; camera box options are also available (7) External integration: Communication integration via Ethernet/IP
Price information
Please feel free to contact us.
Delivery Time
Applications/Examples of results
Pouring process in cast iron foundry
