Eco-friendly cleaning that is gentle on the Earth, with 360-degree air spraying!
● For finishing various drilling processes This product cleans cutting chips and cutting fluids generated during the machining of blind holes and through holes. It rotates at high speed while injecting air from the tip of a slender pipe-shaped nozzle. Compared to conventional nozzles that inject air in one direction, it reduces the amount of air used. The length of the metal part at the nozzle tip is 50 millimeters (standard), and we offer nozzle diameters of 3.5 millimeters and 5 millimeters.
Inquire About This Product
basic information
■Specifications Item Number Nozzle Diameter (mm) Tip Length (mm) Total Length (mm) Air Pressure Connection Part M735CH35-50-180G 3.5 50 Approximately 180 0.4–0.6 MPa R1/8 M735CH50-50-180G 5
Price range
Delivery Time
Applications/Examples of results
■Main Uses ●Cleaning of chips and cutting fluids generated during machining of blind holes and through holes ●Draining after maintenance and disassembly cleaning, among others
