Automatically generate PDF reports from the measurement results of the metal analyzer! 【VANTA】
Rich features support measurements, easily compiling elemental composition, spectral data, and photos into a single PDF report.
◆Report Creation Function The VANTA metal analyzer, equipped with versatile features, can automatically generate PDF reports from measurement results. The report includes the constituent elements and their ratios, as well as the spectral data at the time of measurement. With the Max/Core option, images captured by an optional sample camera are also attached, allowing for an automatically generated report that provides a clear overview of the relevant product and its analysis results. ◆Data Transfer The created PDF data can be output through various methods, including USB memory, USB cable, wireless LAN*, and Bluetooth*. (To be confirmed) Additionally, using a mobile printer allows for immediate printing of analysis results on-site. Please consider this option as well. *Wireless LAN and Bluetooth are optional features.
Inquire About This Product
basic information
■Dimensions: 10.4×29.6×24.1 (W×H×D) ■Weight: Approximately 1.7 to 1.9 kg ■Measurement Element Range: Mg to U ■Power Supply: Removable 14.4V lithium-ion battery or 18V power transformer, 100–240VAC, 50–60Hz, maximum 70W ■Protection Rating: IP54 (partially IP55) compliant ■Drop Test: Passed military standard 810-G, 1.2m drop test ■Operating Environment Temperature and Humidity: -10℃ to 50℃, 10% to 90% ■Data Storage: Built-in system memory (4GB), expandable microSD card (1GB) ■USB: Connectable ■Camera: Max / Core only compatible ■Warranty: 3-year warranty *For more details, please refer to the related links or contact us.*
Price range
Delivery Time
Applications/Examples of results
By customizing the models, methods, and options to suit each application, it is possible to utilize them in various fields such as automotive catalyst recycling, manufacturing quality control and assurance, scrap, and recycling. *For more details, please refer to the related links or feel free to contact us.*
catalog（1）
Download All Catalogs
News about this product（1）
Company information
We handle radiation detection devices (new installations, repurposed updates, regular inspections) and laser cleaners, as well as machinery and materials for steel production. We aim to be a company that can address our customers' needs, serving as the last line of defense to protect everyone from hidden threats. If you have any concerns, please feel free to consult with us!
