Compatible with various chemicals such as acids, alkalis, high-viscosity slurries, etc. No worries about liquid leakage.
In the mining and mineral processing industry, the transport of corrosive chemicals and slurries poses risks of liquid leaks and pump failures, which can lead to decreased work efficiency and increased environmental pollution. Particularly in the mineral processing process, various chemicals are used, necessitating pumps that are highly resistant to chemicals and reliable. Our air-driven diaphragm pumps are compatible with acidic and alkaline chemicals and eliminate concerns about liquid leaks, thereby supporting safe and efficient mineral processing operations. 【Usage Scenarios】 - Transport of corrosive chemicals - Transport of slurries - Use in explosion-proof areas 【Benefits of Implementation】 - Reduces the risk of work interruptions due to liquid leaks - Cuts costs associated with pump failures - Achieves a safe working environment
Inquire About This Product
basic information
【Features】 - Capable of transferring high-viscosity slurries - No leakage of transfer fluid to the outside - Self-priming from dry running is possible, and durability during dry running is high - Easy control with a safe structure - Various material models available 【Our Strengths】 We manufacture and sell industrial equipment and urea water production systems, providing products tailored to our customers' needs.
Price range
Delivery Time
Applications/Examples of results
For more details, please check the PDF document or feel free to contact us.
Line up（10）
| Model number | overview |
|---|---|
| AODD-15-PP-TPT | Maximum discharge capacity 57L/min, maximum particle diameter for transfer 2.5mm, air connection port size 1/4 (8A), connection port Rc male thread 15A, 20A. |
| AODD-25-PP-TPT | Maximum discharge capacity 157L/min, maximum particle diameter for transfer 4mm, air connection diameter 1/2 (15A), connection diameter Rc male thread/flange 25A. |
| AODD-40-PP-TPT | Maximum discharge capacity 385L/min, maximum particle diameter for transfer 5mm, air connection diameter 1/2 (15A), connection diameter Rc male thread/flange 40A. |
| AODD-50-PP-TPT | Maximum discharge capacity 587L/min, maximum particle diameter for transfer 6mm, air connection diameter 1/2 (15A), connection diameter Rc male thread/flange 50A. |
| AODD-80-PP-TPT | Maximum discharge capacity 1060L/min, maximum particle diameter for transfer 9.4mm, air connection diameter 3/4 (20A), connection diameter Rc male thread/flange 80A. |
| AODD-15-KY-TTT | Maximum discharge capacity 57L/min, maximum particle diameter for transfer 2.5mm, air connection port size 1/4 (8A), connection port Rc male thread 15A, 20A. |
| AODD-25-KY-TTT | Maximum discharge capacity 157L/min, maximum particle diameter for transfer 4mm, air connection diameter 1/2 (15A), connection diameter Rc male thread/flange 25A. |
| AODD-40-KY-TTT | Maximum discharge capacity 385L/min, maximum particle diameter for transfer 5mm, air connection diameter 1/2 (15A), connection diameter Rc male thread/flange 40A. |
| AODD-50-KY-TTT | Maximum discharge capacity 587L/min, maximum particle size for transfer 6mm, air connection diameter 1/2 (15A), connection diameter Rc male thread/flange 50A. |
| AODD-80-KY-TTT | Maximum discharge capacity 1060L/min, maximum particle diameter for transfer 9.4mm, air connection diameter 3/4 (20A), connection diameter Rc male thread/flange 80A. |
catalog（6）
Download All Catalogs
Company information
We are engaged in the manufacturing and sales of industrial machinery and urea water production equipment.
