Dimension arrangement as intended by the designer! Significant reduction in design man-hours.
In the furniture industry, accuracy and efficiency in design drawings are essential. Furniture design, which combines complex shapes and diverse parts, often requires significant time for dimension notation and is prone to manual errors. "Raksun" is software that analyzes the shape information of 2D drawings and assists in dimension placement according to the designer's intent. By simply selecting the target rectangle, it automatically generates dimensions based on rules. It achieves a "visually appealing arrangement" that was difficult with the automatic functions of general-purpose CAD, dramatically reducing manual labor. 【Usage Scenarios】 - Dimension notation for part drawings - Efficient dimension addition to 2D drawings - Systematizing the know-how of experienced designers to support younger designers in drafting 【Benefits of Implementation】 - Labor reduction: Significantly reduces the effort required for manual dimension input. - Quality stabilization: Reduces human errors and minimizes variations among designers. - Smoother collaboration: Prevents discrepancies in interpretation during later processes through common rules for drafting. In addition to standalone use, "Raksun" can be flexibly customized to fit the specific design environment of customers. By incorporating unique dimension creation rules into the system, a more practical environment can be established. Please feel free to consult us.
Inquire About This Product
Related Videos
basic information
【Features】 - Automatically arranges necessary dimensions such as outline dimensions and hole spacing by simply selecting a shape and pressing a button. - Supports dimension arrangement in line with the designer's intent. - Achieves "aesthetically pleasing arrangement" that was difficult with general-purpose CAD automatic functions. - Dramatically reduces manual labor. - Compatible with AutoCAD 2025, 2026. - Compatible with AutoCAD Architecture, Mechanical, MEP 2025, 2026. 【Our Strengths】 Since our establishment in 1984, we have consistently faced the diverse challenges faced by the manufacturing industry. By merging our customers' extensive know-how with our expertise in three-dimensional shape processing technology, we provide solutions that are truly beneficial to the manufacturing field.
Price range
Delivery Time
Applications/Examples of results
Automatically displays dimensions by specifying the presence or absence of dimension output and the display position.
