The First Step in Vehicle Network Analysis — Learning Vehicle Spy from Data Visualization to Control in Practice
[Target Audience] - Engineers involved in the analysis of in-vehicle networks (CAN, LIN, Ethernet) - Those who are using Vehicle Spy for the first time or want to systematically acquire the basics - Individuals conducting data monitoring and simulation in ECU development and verification tasks [Overview] This course is a program designed to acquire the basic functions of Vehicle Spy through practical exercises. It covers fundamental operations such as loading databases, operating the Messages View, filtering, and sending messages, as well as signal plotting and creating graphical panels. By combining short lectures with practical tutorials, participants will efficiently acquire the skills necessary for data analysis and management.
Inquire About This Product
basic information
[Agenda of the Seminar] 1. Overview of Vehicle Spy and Screen Configuration 2. Loading and Setting Up Databases (DBC, ARXML, etc.) 3. Monitoring in Messages View 4. Sending Messages 5. Handling Log Data 6. Plotting Signals 7. Creating Graphical Panels 8. Summary and Q&A
Price range
Delivery Time
Applications/Examples of results
[Application Examples of Seminar Content] 1. Network Monitoring - Monitoring CAN/LIN bus traffic during vehicle diagnostics - Real-time analysis of Ethernet packets 2. Data Logging Configuration - Trigger logging configuration under specific conditions - Data collection setup for long-duration driving tests 3. ECU Simulation - Bench testing through simulation of missing ECUs - Building custom gateways using Function Blocks 4. Signal Analysis and Visualization - Trend analysis of sensor data - Understanding the correlation between multiple signals
Company information
In 1994, Intrepid Control Systems was established in the suburbs of Detroit, Michigan, and since then, we have been delivering the latest development tools that support various in-vehicle communication standards to customers around the world. We provide development tools for CAN/CANFD, LIN, Automotive Ethernet, BroadR-Reach, FlexRay, MOST, Keyword2000, ISO14229, ISO9141, UART, J1939, J1850, GMLAN, I2C, SPI, and more. Our customers range from large corporations included in the Fortune 100, major OEMs, to individuals. In addition to a global network of distributors, we have branches in the USA, Japan, China, India, Germany, the UK, and South Korea, where we offer direct sales and technical support. We also actively host seminars in the automotive industry, participate in exhibitions, and contribute in areas such as technical papers.
