High-performance heat-insulating sheet featured in the technical magazine "Coating Technology," August 2025 issue!
High-performance heat-insulating sheet "Netsu Mamore"
Practical Method for Significantly Reducing Heat Loss from Furnaces through Insulation Construction: Explanation
The high-performance heat shielding sheet "Netsu Mamore" is: ★ A sheet that can cut almost all radiated heat due to its 99% pure aluminum coating. ★ It is extremely thin at 0.2mm, lightweight, flexible, and easy to install (SP-PRO, SP-HTR). ★ It contributes to improving the working environment for operators. ★ By simply applying it to high-temperature equipment in factories, such as drying ovens, manufacturing furnaces, kilns, and piping, it significantly reduces heat loss from the equipment. ★ It greatly reduces fuel costs, enhances productivity, and contributes to energy savings and CO2 emission reductions. ★ Thanks to a special surface treatment, it is resistant to corrosion from acids and alkalis, as well as electrolysis (SP-PRO, SP-CH, SP-Air, SP-SRX), and has no aging deterioration, allowing for over 10 years of use. ★ There is also a heat-insulating mat that combines a heat shielding sheet and an insulating mat, which does not get hot to the touch. 【Achievements and Application Examples】 * High-temperature facilities such as drying ovens, boilers, kilns, and piping within factories * Various outdoor control panels * Attics and mid-roofs of factories, warehouses, and facilities
Inquire About This Product
Related Videos
basic information
For more details, please refer to the materials. Feel free to contact us as well.
Price range
Delivery Time
※Please contact us.
Applications/Examples of results
Installation Examples ■ Protecting workers and surrounding equipment from radiant heat of high-temperature equipment inside factories Example: Protection of control panels in front of rolling equipment Preventing equipment deterioration and malfunction ■ Preventing equipment deterioration and malfunction of outdoor distribution boards and control panels Preventing temperature rise inside outdoor distribution boards exposed to direct sunlight in summer and control panels near high-temperature equipment ■ Installation under roofs, in ceilings, and on walls Reducing the temperature inside buildings to prevent heatstroke. Lowering air conditioning operating rates for energy-saving effects. ■ Maintaining constant temperature for chemical storage and precision processing equipment Reducing the impact of temperature changes in summer and winter to stabilize quality.
Detailed information
-
The apparent temperature captured by a thermal camera on a mug with hot water covered with a heat-insulating sheet.
Line up（13）
| Model number | overview |
|---|---|
| SP-PRO | General-purpose non-combustible, non-combustible certification (Ministry of Land, Infrastructure, Transport and Tourism), corrosion prevention treatment, waterproof, thickness 0.2 mm, temperature range -70°C to 90°C. |
| SP-HTR | High strength, non-combustible certification (Ministry of Land, Infrastructure, Transport and Tourism), corrosion-resistant processing completed, thickness 0.2 mm, temperature resistance +130°C (can be adapted to +220°C depending on the construction method). |
| SP-FABW | Polyester material curtains, roll screens, etc. Temperature resistance up to 80°C, thickness 0.3mm. |
| SP-SRX | Curtains, roll screens, etc. Temperature range: -70℃ to 90℃ Thickness: 0.2mm |
| SP-CH | Condensation prevention measures - wall, non-combustible certification (Ministry of Land, Infrastructure, Transport and Tourism), patent application in progress, cold insulation measures, condensation prevention measures, corrosion prevention treatment, thickness 6mm, -20℃ to 70℃. |
| SP-Air | Non-combustible thermal conductivity, thermal conductivity, application for non-combustible certification (Ministry of Land, Infrastructure, Transport and Tourism) in progress, corrosion prevention processing, thickness 0.2 mm, applicable temperature -70℃ to 90℃. |
| P-AL8s | Heat insulation and thermal insulation effects for machinery and equipment, suitable for high-temperature equipment, thickness 8 mm, temperature resistance up to 200°C. |
| SP-AL25 | Heat insulation + thermal insulation effect for machinery and equipment, thickness 25mm, suitable for temperatures up to 400℃. |
| SL-G8 | High-temperature equipment, easy heat insulation + thermal insulation, thickness 8mm, temperature resistance up to 200℃. |
| SL-G20 | High-temperature equipment, thickness 20mm, operating temperature up to 200℃. |
| SL-M10 | Insulation material melamine sponge for food factories and clean rooms, thickness 10mm, temperature range (safe operating temperature 150°C, maximum 240°C). |
| SL-M15 | Insulation material melamine sponge for food factories and clean rooms, thickness 15mm, temperature range (safe operating temperature 150°C, maximum 240°C). |
| SL-E6 | Insulation material special elastomer for condensation prevention in low-temperature piping, thickness 6mm, temperature range -200 to 125℃. |
