Based on the model, not the drawing (Orizuru 3D)

Don't just finish by drawing. Move the model to the next stage.

The concept of advancing manufacturing based on digital models such as 3D is important for sharing design information more accurately and using it consistently through to later processes. In operations centered around drawings, there are often situations where communication and reinterpretation are cumbersome, but by focusing on models, it becomes easier to minimize discrepancies in information. However, in practice, even when models are created, actual operations may revert to drawings or individual confirmations. As a result, information held during design can be lost midway through the process, often leading to re-checking and inconsistencies in judgment. The tool that aims to establish this model-centric approach in practice is 'Orizuru 3D'. Through shape recognition, automatic estimation, and lightweight 3D visualization, it expands design data into estimation, procurement, and manufacturing process design, making models easier to use in subsequent processes. 【Features】 ■ Automatic estimation ■ Lightweight 3D rendering in a web browser *For more details, please download the PDF. ■ Reference Article How does manufacturing change with MBE (Detailed Design)? Features of Model-Based Development https://www.cct-inc.co.jp/koto-online/archives/76
