A planetary ball mill equipped with four turntables that can accommodate grinding jars ranging from 12ml to 500ml.
The planetary ball mill can accommodate ultra-fine grinding. It is suitable not only for mixing and grinding for sample preparation but also for advanced applications such as colloidal grinding and mechanical alloying. The powerful combination of two centrifugal forces from rotation and revolution enables grinding in a short time. The PM400 is a robust floor model with four rotating platforms.
Inquire About This Product
basic information
Powerful and rapid crushing down to the nano level The planetary ball mill achieves powerful crushing by combining two centrifugal forces: revolution and rotation. This significantly shortens the crushing time. The PM400 is a robust floor model. It is equipped with four rotating platforms that can accommodate grinding jars ranging from 12ml to 500ml. By stacking grinding jars of up to 80ml, it can process eight samples at once. Additionally, a model with two rotating platforms is also available. With a large effective revolution diameter of 300mm and a selectable revolution speed from 30rpm to 400rpm, it boasts powerful crushing capability, allowing for crushing down to submicron levels in a short time. 【Features】 ■ Supports long hours of continuous use ■ Equipped with a reverse function to reduce agglomeration ■ Stable rotation for highly reproducible crushing results ■ Up to 10 crushing conditions can be registered ■ Condition input is interactive while viewing the LCD screen (Japanese display) ■ Automatic ventilation for the crushing chamber ■ CE mark compliant with European safety standards
Price information
-
Delivery Time
Applications/Examples of results
■ Agriculture ■ Biotechnology ■ Ceramics, Glass ■ Chemical Products ■ Building Materials ■ Environmental Testing ■ Pharmaceuticals ■ Metallurgy and Metallurgical Engineering
catalog（1）
Download All Catalogs
Company information
Varda Scientific covers a wide range of products, from sample grinding, crushing, homogenization, and heat treatment for laboratory use, to particle size measurement, component analysis, cutting, polishing, embedding, and hardness testing. Varda Scientific has five brands: Leco, QATM, Carbolite Gero, Eltra, and MRB. Since 1999, we have been operating as Leco Corporation, handling products from Leco and Leco Technology. On January 1, 2014, we began handling Carbolite Gero, and at the same time, in line with the increase in the number of brands we handle, we changed our company name to Varda Scientific Corporation. In 2018, we started handling ATM and Qness, and in June 2019, MICROTRAC and Microtrac Bell joined the Varda Scientific Group. As of May 1, 2020, ATM and Qness merged to become QATM, further enhancing our capabilities and allowing us to better meet our customers' needs.
