Bulk materials are reduced without generating dust! We provide sampling samples that eliminate errors!
The "Rotary Tube Divider PT 200" is an extremely effective rotary divider for the subdivision of bulk materials. Samples fed into the hopper of the sample feeder are conveyed through a chute to a cone that rotates at a constant speed of 50 rpm. The sample collection ports at the bottom cone can have 1, 2, or 3 openings, and the ratio of subdivision can be adjusted by changing the width of the slots in the collection ports. As the tube inside the upper cone rotates, samples are collected from the collection port, while the remainder is collected in a 30L discharge sample container. 【Features】 ■ Precise subdivision even for large samples ■ Modular structure ■ Adjustable subdivision ratio ■ Sample collection options of 1 to 3 ■ Smoothly removable sample collection ports and easy-to-tighten bottom cone ■ Suitable for both batch and continuous operation ■ Maintains a constant rotational speed ■ Automatic sample feeding from synchronized DR100 ■ Subdivision compliant with DIN51701 *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
basic information
【Specifications】 ■Nature of input sample: Bulk material ■Input particle size: ≤ 10 mm ■Rotation speed: 50 rpm ■Number of samples collected: 1 / 2 / 3 (depending on the number of bottom cones) ■Time setting: Digital, 1, 3, 5, 10 - 60 minutes / Continuous operation ■Slot width, steplessly adjustable ・0 - 159 mm ・0 - 110 mm ・0 - 53 mm ■Maximum division ratio ・1 x 1:5 ・2 x 1:7.2 ・3 x 1:15 ■Minimum division ratio ・1 x 1:26 ・2 x 1:26 ・3 x 1:26 ■Discharge sample container capacity: 30 l ■Collection bin capacity: 250 ml / 500 ml ■Voltage: 100-240 V, 50/60Hz ■Power supply: Single phase ■W x H x D: 520 x 1050 x 551 mm / 572 mm x 1307 x 551 incl. DR 100 ■Body weight: ~ 46 kg (incl. DR 100) ■Standards: CE *For more details, please refer to the PDF document or feel free to contact us.
Price information
-
Delivery Time
Applications/Examples of results
【Application Examples】 ■ Coffee, cement clinker, nuts, filling materials, chemicals, soil, flour, ■ Construction materials, sand, seeds, grains, powdered detergent, fertilizers, iron powder, minerals, ... *For more details, please refer to the PDF document or feel free to contact us.
