Thoroughly analyze the hidden issues in design engineering and significantly reduce design man-hours and lead time in three steps!
We will introduce a case study of business improvement using the specialized 3D CAD "iCAD SX" for mechanical design. At Komatsu NTC Corporation, the design process of transfer machines was thoroughly analyzed, and it was identified that the dedicated design of some modules was a major cause of increased man-hours. (There were covers of both 1500mm and 1510mm.) In order to standardize and regulate the components that require dedicated design, the company decided to transition to 3D design and utilized "iCAD SX," which has lightweight data and easy modifications. In addition to successfully halving the lead time for module design, they have further reduced design man-hours by establishing an automatic drawing system for tooling diagrams. [Main Effects of Implementation] - By converting each part drawing to 3D and standardizing and regulating components, lead time was halved. - The 3D conversion of piping design reduced the total man-hours for piping design and manufacturing by nearly 30%. [Download Materials] - Currently available for limited access on the special site. Please click the link below. ▼▼▼ Download from here ▼▼▼
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX" is a purely domestic 3D CAD specialized for mechanical equipment design. It continues to pursue a commitment to being "light" and "fast" through its unique CAD kernel technology, achieving overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information accumulated in 3D data with ease. The extensive "manufacturing information" accumulated can be utilized not only in design but also in manufacturing and maintenance services, contributing to the reduction of development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Delivery Time
P3
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Examples of design targets: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveying equipment, industrial machinery and plants, food machinery, jigs and tools, precision machinery such as motors, and others.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
