Realizing a development design system that meets strict delivery deadlines and high-density design with 3D CAD.
We will introduce a case study of business improvement using the specialized 3D CAD for mechanical design, "iCAD SX." At "Shinwa Controls Co., Ltd.," in order to respond to the market's demand for speedy short delivery times and the need for further densification of equipment, the decision was made to transition to 3D design for chillers (liquid temperature control devices) used in semiconductor manufacturing equipment. Having previously failed in their transition to 3D design, the company chose "iCAD SX" with the perspective of whether it could truly be applied to their product design and yield effective results. After migrating to iCAD SX, the company's challenges were resolved, enabling information sharing between the design and manufacturing departments, which had previously been difficult. Considerations for piping layouts, which were conducted in later processes, could now be advanced to the conceptual design stage, promoting a reduction in lead time for design and manufacturing, as well as enhancing product quality and functionality. [Main Effects of Implementation] - Streamlining of the development and design process - High-density design of equipment through scrap and build - Significant reduction in rework during the manufacturing stage [Download Materials] - Currently available for limited access on the special site. Please click the link below. ▼▼▼ Download from here ▼▼▼
Inquire About This Product
Related Videos
basic information
iCAD Corporation's 'COLMINA Design and Manufacturing Support iCAD SX' is a purely domestic 3D CAD specifically designed for mechanical equipment design. It continues to pursue a focus on being "light" and "fast" through its unique CAD kernel technology, achieving overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information accumulated in 3D data with ease. The extensive "manufacturing information" accumulated can be utilized not only in design but also in manufacturing and maintenance services, contributing to the reduction of development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Delivery Time
P3
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Design target examples: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveying equipment, industrial machinery and plants, food machinery, jigs and tools, precision machinery such as motors, and others.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
