Tohoku University Technology: Polycrystalline Heusler alloy thin film: T20-2968
Polycrystalline Heusler alloy film exhibiting performance comparable to that for a single crystal, which can be formed on a flexible substrate
Co-based Heusler alloy such as Co2MnGa or Co2MnAl has attracted attention as candidate materials for high-sensitivity sensor and high-efficiency thermoelectric conversion element thanks to their large anomalous Nernst and Hall effects. In order to realize these excellent properties, it is thought that a single crystalline bulk material or a thin film grown on a single crystalline substrate is necessary. Thus, such single crystalline samples have been produced. Considering that those materials are applied to actual devices, it is necessary that a polycrystalline film, which does not use a single crystalline substrate, shows the property equivalent to those of single crystalline material. This invention is able to provide a “polycrystalline Heusler alloy thin film" that does not require a single crystalline substrate, while showing the properties of anomalous Hall angle (θAH~7.5%) and anomalous Nernst coefficient (SANE~5μV/K) comparable to a single crystalline thin film. It can promote the control of crystal orientation and the improvement of crystallinity by sandwiching the polycrystalline layer with an insulating AlN layer.
Inquire About This Product
basic information
For details, please contact us or refer to the PDF.
Price range
Delivery Time
Applications/Examples of results
For details, please contact us or refer to the PDF.
