Tohoku University Technology: High-Efficiency MnSi based thermoelectric material : T16-036
Highly efficient MnSi baset material
Conventional manganese-silicide-based thermoelectric material MnSix has excellent thermoelectric property and thermal shock resistance. For example, the output factor S2σ (where S is the Seebeck coefficient and σ is the electrical conductivity), which is one of the thermoelectric property, is maximum 2.22 mW/K2m at 500C. However, MnSi (manganese monosilicide) is deposited in the layers in MnSix c-axis direction with a period of several tens microns, which causes a decrease of the figure of merit Z (output factor S2σ divided by thermal conductivity κ) of the material. This invention limits the MnSi layer deposition and provides a thermoelectric material with an excellent thermoelectric property and its manufacturing method.
Inquire About This Product
basic information
For details, please contact us or refer to the PDF.
Price range
Delivery Time
Applications/Examples of results
For details, please contact us or refer to the PDF.
