Simultaneously achieving the difficult balance of "shortening delivery times" and "reducing design defects" in 3D CAD.
We will introduce a case study of business improvement using the specialized 3D CAD "iCAD SX" for mechanical design. "NFT" is expanding its business in the design and manufacturing of precision molds for semiconductors, facing various issues due to the increasing complexity and shorter delivery times of the ordered equipment. Having previously experienced unsuccessful transitions to 3D design, the company prioritized "the performance of creating 3D models based on existing 2D drawing data" and selected "iCAD SX" from multiple 3D CAD options. As a result, they have not only reduced the occurrence of design defects associated with shorter delivery times and decreased the man-hours required to produce drawings, but they have also gained significant feedback as a presentation tool. [Main Effects of Implementation] - Man-hours required to produce drawings reduced by up to 20% - Reduction in design defects (zero defects in unit design) - Significant reduction in man-hours for interference checking [Download Materials] - Currently available for limited viewing on the special site. Please click the link below. ▼▼▼ Click here ▼▼▼
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX" is a purely domestic 3D CAD specialized for mechanical equipment design. It continues to pursue a commitment to being "light" and "fast" through its unique CAD kernel technology, achieving overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information accumulated in 3D data with ease. The extensive "manufacturing information" accumulated can be utilized not only in design but also in manufacturing and maintenance services, contributing to the reduction of development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Delivery Time
P3
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Design target examples: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveying equipment, industrial machinery and plants, food machinery, jigs and tools, precision machinery such as motors, and others.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
