Hirosaki Univ. Technology : Thin and flexible force sensor Related patents (1/4):K23-011_K23-022_K23-030_K24-002
Thin, highly integrated sensor capable of measuring low stress range
Measurement of shear stress and contact stress provides important information in various fields such as robotics, medical, digital, and direct skin contact product development Conventional triaxial stress sensors have thick and rigid shapes, so it has been difficult to directly measure shear stress and contact stress in vivo, for example. In order to solve the above problems, the inventor has developed the following sensors. 1. Patent No. JP5688792 * Related Patent (2/4) Thin sensor capable of measuring shear stress and contact stress simultaneously 2. Patent No. JP6753615 * Related Patent (3/4) Highly integrated sensor technology 3. Patent No. JP7466214 * Related Patent (4/4) A laminated sensor capable of measuring even in a low stress range based on the principle of 1. The present invention is a thin, highly integrated sensor combining the above technologies. Demonstration experiments for various applications have been conducted, and the practical application of this technology is expected.
Inquire About This Product
basic information
For more details, please contact us or refer to the PDF.
Price range
Delivery Time
Applications/Examples of results
For details, please contact us or refer to the PDF.
