Dimension layout as intended by the designer! Streamlining dimension notation in 2D drawings.
In the machinery industry, accurate verification of the range of motion is required during the product design stage. Dimensioning in 2D drawings is essential for confirming the arrangement of parts and checking for interference, but manual dimension placement is time-consuming and prone to errors. Raksun addresses this challenge by analyzing the shape information of 2D drawings and supporting dimension placement that aligns with the designer's intent. 【Usage Scenarios】 - Dimensioning for part drawings with complex shapes and numerous holes - Efficient dimension addition to 2D drawings - Systematizing the know-how of experienced designers to support younger designers in drafting 【Benefits of Implementation】 - Labor reduction: Significantly reduces the effort required for manual dimension input. - Quality stabilization: Reduces human error and minimizes variation among different designers. - Smooth collaboration: Prevents discrepancies in interpretation in later processes through common rules for drafting. "Raksun" offers flexible customization tailored to the specific design environment of each customer. By incorporating unique dimension creation rules established by the company into the system, a more practical environment can be built. Please feel free to consult us.
Inquire About This Product
Related Videos
basic information
【Features】 - Automatically arranges necessary dimensions such as outer dimensions and hole spacing by simply selecting a shape and pressing a button. - Analyzes the shape information of 2D drawings to assist in dimension arrangement that aligns with the designer's intent. - By pre-setting rules such as reference planes and dimension directions, dimensions are automatically generated based on these rules by simply selecting the target in a rectangular manner. - Achieves "aesthetic arrangement" that was difficult with the automatic functions of general-purpose CAD. - Dramatically reduces manual labor. - Compatible with AutoCAD 2025, 2026. - Compatible with AutoCAD Architecture, Mechanical, MEP 2025, 2026. 【Our Strengths】 Since our establishment in 1984, we have consistently faced the diverse challenges encountered in the manufacturing industry. By merging our customers' extensive know-how with our expertise in three-dimensional shape processing technology, we provide solutions that are truly beneficial to manufacturing sites.
Price range
Delivery Time
Applications/Examples of results
Automatically displays dimensions by specifying the presence or absence of output and the display position.
