Dimension layout according to the designer's intent. Reduces the effort of dimensioning and contributes to improved accuracy.
In the field of mold design, 2D drawings are crucial documents that serve as the foundation for manufacturing instructions. However, the process of accurately and clearly annotating dimensions for complex shapes poses a significant burden on designers. Particularly, arranging dimensions to correctly convey design intent requires skilled experience, and manual annotation not only takes time but also carries the risk of human errors such as oversights and transcription mistakes. "Raksun" addresses the challenges of "man-hours" and "personalization" in the creation of these drawings. 【Usage Scenarios】 - Annotating dimensions on part drawings with complex shapes or numerous holes - Efficiently adding dimensions to 2D drawings - Systematizing the know-how of experienced designers to support younger designers in drafting 【Benefits of Implementation】 - Significantly reduces the effort required for dimension input. - Minimizes human errors and controls variations among different designers. - Prevents discrepancies in interpretation in later processes through standardized drawing rules. In addition to standalone use, "Raksun" can be flexibly customized to fit the specific design environment of our clients. By incorporating the unique dimension creation rules established by the company into the system, a more practical working environment can be built. Please feel free to consult with us.
Inquire About This Product
Related Videos
basic information
【Features】 - Automatically arranges necessary dimensions such as outer dimensions and hole spacing by simply selecting a shape and pressing a button. - Achieves dimension arrangement according to the designer's intent. - Dramatically reduces manual labor. - Analyzes shape information from 2D drawings. - Compatible with AutoCAD 2025 and 2026. - Compatible with AutoCAD Architecture, Mechanical, MEP 2025 and 2026. 【Our Strengths】 Since our establishment in 1984, we have consistently faced the diverse challenges encountered in the manufacturing industry. By combining our customers' extensive know-how with our expertise in three-dimensional shape processing technology, we provide solutions that are truly beneficial to manufacturing sites.
Price range
Delivery Time
Applications/Examples of results
Automatically displays dimensions by specifying the presence or absence of output and the display position.
