Equipment List > Xenon Weather Meter
We can conduct stress reproduction tests in natural environments such as temperature and humidity, light, and salt damage using various environmental testing machines.
This equipment conducts accelerated weather resistance tests using a xenon type. By artificially creating an environment that exposes materials to sunlight, it is possible to perform weather resistance tests that promote degradation even more than in natural environments. Weather resistance refers to the resistance to degradation primarily caused by sunlight, rain, snow, temperature, humidity, and ozone in the natural environment. To evaluate this, it is necessary to conduct outdoor exposure tests or accelerated weather resistance tests using artificial light sources. The xenon weather meter used at JTL is a type of accelerated weather resistance testing machine, utilizing a light source (xenon lamp) that closely approximates the spectral irradiance distribution of ultraviolet and visible light from sunlight. It is capable of conducting weather resistance tests on paints (JIS K 5600-7-7), building materials (JIS A 1415), plastics (JIS K 7350-2), coatings, printed materials, textiles, and more, complying with various standards such as JIS, ISO, and JASO.
Inquire About This Product
basic information
【Xenon Lamp Approximating Sunlight】 Xenon lamps have a spectral radiation intensity distribution that approximates sunlight, allowing for tests that more accurately reproduce sunlight exposure. 【High-Intensity Type with Radiation Intensity of 60–180W/m²】 It also supports high-intensity tests with ultraviolet radiation intensity approximately three times that of sunlight (180W/m²), enabling more effective evaluations. 【Evaluation of Color, Gloss, and Haze Before and After Testing】 As part of the evaluation of the test specimens before and after testing, it is possible to assess color, gloss, and haze using a colorimeter, gloss meter, and haze meter.
Price information
-
Delivery Time
Applications/Examples of results
- Investigation of degradation of plastic products due to sunlight - Investigation of changes in gloss of automotive paint due to sunlight - Investigation of discoloration of printed materials due to sunlight Suga Testing Machine SX75AP ● Light source: 7.5kW water-cooled xenon lamp ● Test items: irradiation, irradiation + rainfall, darkness, darkness + condensation, darkness + rainfall + condensation ● Radiation intensity: 60–180W/m² (300–400nm) ● Irradiation test: BPT 50–95±1℃, humidity 50–60±5% RH ● Darkness test: chamber temperature 38±1℃, humidity 95±5% RH ● Rotation speed: 1, 2, 12 rpm ● Number of samples: up to 54 pieces (sample dimensions: 150×70×1mm)
Company information
Our main business is providing technical services to evaluate the reliability of developed products. We not only provide evaluation data in accordance with standards and regulations, but also propose optimal methods, conditions, and equipment for evaluation purposes, as well as design and manufacture original equipment and jigs for non-standard evaluations. Additionally, we handle three evaluation techniques—measurement, testing, and analysis—comprehensively, allowing us to offer complex services that span diverse equipment and suggest more multifaceted evaluation methods.
