Digital Camera Measurement Automation System VFORM
Digital Camera Measurement Automation System VFORM
The industry's first photo measurement and mapping system has arrived!
**What is VFORM?** It is a system that supports post-processing after three-dimensional measurement with digital cameras. By taking photos with a commercially available DSLR camera, CAD drawings and inspection sheets can be output on the spot. There is no need for expensive specialized measuring equipment, and compared to 3D scanners, it offers advantages such as "portability," "fewer location restrictions," and "measurements in a short time." The post-processing after shooting can be customized for each customer, allowing for the extraction and automatic output of only the desired measurement results. Customers who have requests such as "wanting to model," "wanting to streamline dimensional inspections," "wanting to understand spatial relationships in three dimensions," or "wanting to know the fit with installation locations" are encouraged to contact us freely. **Features** 1. Immediate confirmation of measurement results (outputs deliverables such as CAD drawings and inspection sheets in about 5 minutes after shooting) 2. Various post-processing support (customizes and outputs measurement results to fit the customer's company) 3. Reduction of measurement time and personnel (allows for quick measurements by one person) 4. Streamlining of measurement tasks (eliminates the hassle of moving objects to inspection areas or reference plates) 5. Assurance of measurement results (eliminates measurement errors and variations caused by operators)
Inquire About This Product
basic information
【Product Composition】 1. Software (VFORM) 2. Digital Camera (including lens and flash) 3. Target, reference ruler 【Specifications】 - Accuracy: ±1/20,000 (approximately ±0.5mm/10m) - Shooting distance: approximately 0.5m to 10m (varies depending on conditions) - Minimum number of shots: at least 3 (varies depending on the subject and conditions) 【Implementation Effects】 - Significant reduction in measurement time! (77% reduction) (*) - Significant reduction in post-measurement processing time! (67% reduction) (*) - Enables measurement by a single person! - Reduces errors in measurement tasks! * Based on user performance data from our company
Price information
3.6 million yen and up. The price varies depending on various conditions (measurement targets, measurement methods, deliverables, etc.), so please feel free to contact us.
Delivery Time
※2 months
Applications/Examples of results
【Usage Scenarios】 1. On-site Measurement - I want to create a drawing of the current state of the construction site. - I want to understand the shape of existing structures. - I want to understand the shape of the parts to be replaced. 2. Product Inspection and Installation Accuracy Verification - I want to conduct dimensional inspections of products manufactured in the factory. - I want to understand the installation accuracy of machines within the factory. 3. Stationary Camera Measurement - I want to perform measurements at a specific inspection site. - I want to conduct automatic measurements with a stationary camera (it is not possible to use a handheld camera to capture the object by circling around it). - Example: Vehicle body measurement, leftover material measurement. 4. General Measurement - I want to easily know the three-dimensional coordinates of unspecified objects. - I want to understand the displacement of specific points in experiments, etc.
