Aluminum foil with excellent strength and ductility for the positive electrode current collector of lithium-ion secondary batteries.
We have developed aluminum foil 'KS-81' suitable for improving processing and coating precision, as well as output density, for lithium-ion secondary battery positive electrode current collectors. Thanks to improvements in foil manufacturing technology and foil rolling technology, it has become a very fine metal crystal with high mechanical properties. Additionally, it can be used without compromising processability or basic performance due to the thinning of the aluminum foil. 【Features】 ■ Excellent strength and ductility ■ Ensures conductivity almost equivalent to pure aluminum ■ Offers a wide range of thickness options and can accommodate thinning ■ Cost reduction possible through thinning *For more details, please refer to the catalog or feel free to contact us.
Inquire About This Product
basic information
【Performance (Representative Values)】 *Conductivity is 59 (IACS%) for all thicknesses ○ 10μm Single Gloss Tensile Strength: 255 N/mm Elongation: 1.6% ○ 12μm Single Gloss Tensile Strength: 265 N/mm Elongation: 1.9% ○ 12μm Double Gloss Tensile Strength: 275 N/mm Elongation: 2.5% ○ 15μm Double Gloss Tensile Strength: 275 N/mm Elongation: 3.1% 【Details of Provided Samples】 - Roll samples (for all thicknesses) - Width: Approximately 650 mm - Roll length: Up to 4000 m *For more details, please refer to the catalog, but feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
○ Lithium-ion secondary battery cathode material for automotive use ○ Lithium-ion secondary battery cathode material for consumer use ○ Audio equipment diaphragm *For more details, please refer to the catalog, but feel free to contact us.*
catalog（2）
Download All Catalogs
