It is used in research and development, quality control of raw materials, intermediates, and final products, as well as in product inspection departments.
Advantages - NEW: Amplitude control via microprocessor - Compatible with both dry and wet methods (wet method is optional) - Efficient sieving in a short time - Effective electromagnetic agitation - Three-dimensional classification with vertical, horizontal, and twisting effects, allowing the sample to agitate evenly while transitioning across the entire mesh surface. - Maximum sieve height of 510mm - Digital setting of conditions (amplitude level, timer) - Basic model can be equipped with optional clamp unit type A. - Classification evaluation software EasySieve available - Maintenance-free - Easy to operate with an ergonomic design
Inquire About This Product
Related Videos
basic information
Application: Classification and grading Field: Engineering / Electronics, Glass / Ceramics, Bio, Chemicals / Chemical Products, Geology / Metallurgy, Materials Science, Construction Materials, Environment / Recycling, Pharmaceuticals / Drugs, Agriculture, Food Nature of Input Sample: Powder, Bulk Material, Suspension Measurement Range*: 20 µm - 25 mm Classification Method: Three-dimensional motion Maximum Input Amount: 3 kg Number of Classifications: 9 / 17 Maximum Sieve Frame Weight: 4 kg Vibration Width: Digital, 0.2 - 3.0 mm Time Display: Digital, 1 - 99 minutes Interval Mode: 10 s SOP Configurable: 1 Dry Classification: Yes Wet Classification: Yes USB Interface: - Calibration Certificate: - Usable Sieve Diameters: 100 mm / 150 mm / 200 mm / 203 mm (8") Maximum Sieve Height: 510 mm Clamp Unit: Type B, Type A supports both dry and wet Protection Rating: IP 54 / IP 20 Voltage: 100V-240V, 50/60Hz Power Supply: Single-phase W x H x D: 417 x 212 x 384 mm Body Weight: ~ 35 kg Standards: CE
Price information
-
Delivery Time
Applications/Examples of results
【Application】 - Classification of activated carbon, abrasives, refractory materials, silica gel, diamonds, etc.
catalog（1）
Download All Catalogs
Company information
Varda Scientific covers a wide range of products, from sample grinding, crushing, homogenization, and heat treatment for laboratory use, to particle size measurement, component analysis, cutting, polishing, embedding, and hardness testing. Varda Scientific has five brands: Leco, QATM, Carbolite Gero, Eltra, and MRB. Since 1999, we have been operating as Leco Corporation, handling products from Leco and Leco Technology. On January 1, 2014, we began handling Carbolite Gero, and at the same time, in line with the increase in the number of brands we handle, we changed our company name to Varda Scientific Corporation. In 2018, we started handling ATM and Qness, and in June 2019, MICROTRAC and Microtrac Bell joined the Varda Scientific Group. As of May 1, 2020, ATM and Qness merged to become QATM, further enhancing our capabilities and allowing us to better meet our customers' needs.
