Corrosion prevention measures for SOx scrubber piping and flues! Achieving low cost and short delivery times.
The "Polyglass VE Series" is a glass flake lining that achieves low cost, short delivery times, and high corrosion resistance. The glass flakes in the VE series are ultra-thin films ranging from 1.5 to 3 microns, with uniformity and minimal variation, and are high-quality corrosion-resistant materials free of impurities. By incorporating these glass flakes, the corrosion resistance has been significantly improved, allowing for a reduction in coating thickness. This is a single-coat system that eliminates the need for the primer, intermediate coat, and topcoat layering required with conventional flakes. By applying it directly, it is possible to achieve corrosion resistance equal to or greater than that of traditional methods. 【Features】 ■ Lower cost with VE lining on SS materials compared to expensive SUS steel materials ■ Single-coat system, resin lining material that can be applied using high-pressure spray (1 coat thickness of 500 to 1000μ or more) ■ Resistance to high corrosion environments and chemical agents, compatible with a wide range of pH values ■ Temperature limits (°C): 110 in liquid, 175 in air *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
Related Videos
basic information
【Performance】 ■Specific Gravity (gms/cc): 1.19 ■Solidification Rate: 99.8 ■Adhesive Strength (kg/cm2): 200 ■Barcol Hardness: 45 ■Wear Resistance (mgm): 405 ■Thermal Conductivity (cals/cc/℃): 0.00001 ■Recommended Film Thickness (mm): 0.5 ～ 3.0 *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Achievements】 ■ Corrosion protection of the inner surface of the sludge combustion exhaust gas line ■ Thickeners in a high-temperature slurry environment at the refining plant ■ New tanks for waste liquid and sludge tank, etc., with fluctuating pH levels *For more details, please refer to the PDF document or feel free to contact us.
catalog（3）
Download All Catalogs
Company information
Idea Corporation is a corrosion engineering company that supports problem-solving in manufacturing and maintenance fields, primarily focusing on corrosion and anti-corrosion. We handle products such as anti-corrosion lining construction, laser cleaners, solvent regeneration machines, various pumps, and mixing devices, leveraging the strengths of our group companies. From product selection to demonstrations, tests, and construction, we provide proposals tailored to specific applications and site conditions.
