Designing over 100 production facilities with 3D CAD! Designing and manufacturing specialized machines filled with unique technology without any setbacks!
We would like to introduce a case study of business improvement using the specialized 3D CAD "iCAD SX" for mechanical design. At Denso Corporation, they are internalizing the production equipment for automotive parts. As the equipment became more complex and large-scale, they felt the limitations of 2D inspection through visual checks and decided to transition to 3D design. After acquiring high-end CAD and several mid-range CAD systems, they conducted actual design and benchmarking, ultimately selecting "iCAD SX" as it could handle the assembly of processing machines with over 10,000 parts. As a result, after a trial introduction period, it was officially adopted as the standard 3D CAD for the entire company. They have achieved "no return" by designing over 100 production facilities in 3D. [Main Effects of Implementation] - Labor-saving from detailed drawing design to assembly and design stages - Improvement in design quality, cost reduction, and enhanced competitiveness - High-precision simulation of equipment, robots, and human movements [Download Materials] - Currently available for limited access on the special site. Please click the link below. ▼▼▼ Click here ▼▼▼
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX" is a purely domestic 3D CAD specialized for mechanical equipment design. It continues to pursue a focus on being "light" and "fast" through its unique CAD kernel technology, achieving overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information accumulated in 3D data with ease. The accumulated extensive "manufacturing information" can be utilized not only in design but also in manufacturing and maintenance services, contributing to a reduction in development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Delivery Time
P3
Applications/Examples of results
<Members Only> Currently available exclusively on the iCAD special site. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Design target examples: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveying equipment, industrial machinery/plants, food machinery, jigs and tools, precision machinery such as motors, and more.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX V8' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
