Visualization of design! 3D CAD that realizes the advancement of work processes.
At "Nippon Steel & Sumitomo Metal Corporation Hiroshima Works," there were issues arising from changes in the design of large resin pellet manufacturing equipment (industrial machinery and plant facilities) that could not be covered by 2D planning drawings. The company decided to transition to 3D design with the aim of front-loading. After experiencing difficulties with a history-based 3D CAD that was not well established, they selected "iCAD SX," which does not suffer from slow response times even when handling tens of thousands of parts. As a result, they were able to enhance design reviews and disclose design information early using 3D models, leading to an advancement in the design workflow and cost reductions through the compactification of equipment. [Main Effects of Implementation] - Creation of overall planning drawings was halved (reduced from 2 months to less than 1 month) - Significant reduction in assembly interference and a 20% reduction in design support personnel - Cost reduction due to equipment compactification (e.g., 43% reduction in volume) [Download Materials] - Currently available for limited viewing on the special website. Please click the link below.
Inquire About This Product
Related Videos
basic information
iCAD Corporation's "COLMINA Design and Manufacturing Support iCAD SX" is a purely domestic 3D CAD specialized for mechanical equipment design. It continues to pursue a commitment to being "light" and "fast" through its unique CAD kernel technology, achieving overwhelming high-speed processing performance. In the design of large-scale machinery and entire production equipment lines, it can handle vast amounts of design information stored in 3D data with ease. The accumulated extensive "manufacturing information" can be utilized not only in design but also in manufacturing and maintenance services, contributing to the reduction of development lead times. It is adopted by many domestic companies and offers robust support unique to domestic development.
Price information
Mid-range 3D CAD
Delivery Time
P3
Applications/Examples of results
Customer case studies are exclusively available on the iCAD special site within iPros. ▼ Download case studies (iPros - iCAD special site) https://premium.ipros.jp/icad/catalog/category/66243/ Design target examples: Labor-saving devices, machine tools, semiconductor manufacturing equipment, production equipment, conveying equipment, industrial machinery/plants, food machinery, jigs and tools, precision machinery such as motors, and more.
Company information
To support Japan's manufacturing, iCAD Corporation has developed the specialized 3D CAD software 'iCAD SX' focused on mechanical design. iCAD achieves high-speed response, handling 3 million parts in just 0.2 seconds, allowing for stress-free design consideration and verification of large-scale equipment and entire production lines that can consist of tens of thousands of components. By leveraging its ability to manage vast amounts of information, it is possible to accumulate and utilize the design information necessary for equipment development, including piping, wiring, and control (movement), all within a single CAD data set. This single data set can be used across various scenarios and departments, from design to manufacturing, assembly, and maintenance. This leads to a reduction in development lead time and an improvement in design quality.
