[Vacuum Pump Application Catalog] A Smart Choice for Energy Saving and Carbon Neutrality
Achieve energy savings with vacuum pumps! Introducing electric vacuum end effector and vacuum pumps.
This catalog features application examples of the electric vacuum end effector and vacuum pumps used in vacuum lifting systems. To support energy-saving efforts and carbon neutrality, download this catalog to explore our vacuum pump solutions. 【Featured Products】 1. Electric Vacuum End Effector “e‑VEE” 2. HK-400A 3. VP0660 4. VP0940 5. DP0410 / DP0410T For more information, please refer to the PDF or contact us at your convenience.
Inquire About This Product
basic information
【Specifications】 ■ Electric Vacuum End Effector Attainable Vacuum: -66.6 kPa Free Air Displacement: 7.5 L/min Rated Voltage: 24 V DC ■ HK-400A Operating Pressure Range: 0 to 100 kPa Flow Rate: 400 mL/min Rated Voltage: 24 V DC ■ VP0660 Attainable Vacuum: -80 kPa Free Air Displacement: 25 L/min Rated Voltage: 115 V / 230 V AC ■ VP0940 Attainable Vacuum: -53.3 kPa Free Air Displacement: 60 L/min Rated Voltage: 115 V / 230 V AC ■ DP0410 / DP0410T Attainable Vacuum: -77.3 kPa Free Air Displacement: 18 L/min (DP0410), 34 L/min (DP0410T) Rated Voltage: 24 V DC
Price range
Delivery Time
Applications/Examples of results
For details, please refer to the PDF or feel free to contact us.
catalog（5）
Download All Catalogs
