To Tsukasa Electric Co., Ltd., a manufacturer of small gear motors, we would like to introduce a case study of the implementation of "iCAD SX." The company adopted 3D CAD to design high-value-added products quickly. The product was chosen due to its excellent operability, ease of understanding for designers familiar with 2D CAD, simple transition, and the ability to utilize existing assets in the form of 2D drawings. As a result of the implementation, they were able to reliably perform interference checks and speed up prototyping by providing 3D data. [Case Overview] ■ Reasons for Selection - Excellent operability - Easy transition for designers accustomed to 2D CAD - Ability to use existing assets in the form of 2D drawings - Good cost performance, achieving the ideal environment of one unit per person *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
basic information
【Results】 ■ Successfully able to conduct interference checks ■ Achieved significant results in reducing lead time during the prototyping phase ■ Utilized text information extraction functionality to automate BOM creation and achieve data integration with the production management system *For more details, please refer to the PDF document or feel free to contact us.
