Active in international transport of sake | Introduction of case studies using wireless seal-type temperature loggers
AZN5200/Axzon Corporation
Products sensitive to temperature changes, such as sake, can be managed safely. With the built-in LED, you can check for temperature deviations just by touching it, and data during transportation can also be recorded.
Temperature management is essential for maintaining the quality of sake. In particular, unpasteurized sake, ginjo sake, and daiginjo sake are sensitive to temperature changes, and managing temperature during transportation is key to preserving quality. Axzon's wireless seal-type temperature logger has been developed to address these challenges. 【Features and Use Cases】 ● Disposable and no need for collection: Can be introduced from just one unit without specialized equipment or cloud contracts. ● Built-in LED visualizes temperature deviations: The recipient can check deviations from the set temperature with just a touch. ● Temperature data recording during transportation: Records temperature history, which can be used as evidence for quality management. These features make temperature management during the international transportation of sake easier and ensure quality preservation. ＼Product catalog available now／ For more details, please view the PDF data from "Catalog Download." If you have any questions about the product or would like to request a quote, please feel free to contact us.
Inquire About This Product
basic information
External dimensions (Width x Height): 100 x 33 mm Interface: UHF band RFID (contactless) RFID communication standard: ISO/IEC18000-63/ EPC C1G2 TID Memory: 1024bit (64word) EPC Memory: 256bit (16word) User Memory (Flash): 4,096 words of log data User Memory (MTP): 2304 bits (144 words) Reserved Memory: 320 bits (20 words) Measurement target: Temperature Measurement range: -30℃ to +65℃ Measurement accuracy: +/- 0.5ºC (30ºC to 60ºC, Typical) +/- 1.0ºC (-25ºC to 60ºC, Typical) Measurement display resolution: 0.125 ℃ Recording interval: 1 second to 480 minutes Recording capacity: 4096 entries Temperature recording time (example): At 1 second interval: 1.13 hours, at 4 hours interval: 682 days (1.86 years), at 8 hours interval: 1365 days (3.74 years) Power supply: Printed battery
Price range
Delivery Time
Applications/Examples of results
Cold Chain (Frozen and Refrigerated) Transportation - Temperature management during the transportation of pharmaceuticals, specimens, and chemicals - Temperature measurement and management of refrigerated storage, storage rooms, and showcases - Temperature management in laboratories, analysis/testing rooms, factories, and kitchens - Temperature management of food, vegetables, fruits, and sweets - Temperature management for fermentation and aging of foods such as alcohol, soy sauce, miso, and bread - Temperature management of semiconductors and precision components
